VL-T-ADB Series

Trident Back Light

TRIDENT
  • Brightness: Built-in brightness control function.
  • Compliant: RoHS compliant.
  • Design: T-Slot design.
  • Over Drive: Built-in over drive function. (Duration max. 20mS, duty cycle 10%).
  • Trigger: Built-in brightness control function.
VL-T-ADB Series
Codice variante Color Connector Dimension of Lighting Area (mm) Operating Current (Continuous Mode / Strobe Mode) Operating Voltage Pdf Spec
VL-T-ADB1515R-1 Red M12 (5Pin Male) 150 x 150 0.55A / 1.0A DC24V
VL-T-ADB1515W-1 White M12 (5Pin Male) 150 x 150 0.5A / 1.0A DC24V
VL-T-ADB3030R-1 Red M12 (5Pin Male) 300 x 300 2.0A / 4.0A DC24V
VL-T-ADB3030W-1 White M12 (5Pin Male) 300 x 300 2.0A / 4.0A DC24V
