VS-LQL Series

Telecentric lens for Optotune liquid lens

VS TECHNOLOGY
  • Focus: Adjustable within working distance range
  • Solution: Fast-focusing solution
Leaflet
VS-LQL Series
Variant code Co-axial Lighting Opt. Mag Sensor Size (max.) WD (mm) Working F/# Pdf Spec
VS-TCH2-65-LQL1 - 1.9x-2.0x 2/3" 63.6-66.3 12.9-13.7
VS-TCH2-65CO-LQL1 O 1.9x-2.0x 2/3" 63.6-66.3 12.9-13.7
VS-TCH4-65-LQL1 - 3.7x-4.0x 2/3" 64.8-65.3 16.6-17.9
VS-TCH4-65CO-LQL1 O 3.7x-4.0x 2/3" 64.8-65.3 16.6-17.9
VS-THV1-110/S-LQL1 - 0.9x - 1.0x 1" 107.3 - 121.7 9.3 - 10.3
VS-THV1-110CO/S-LQL1 O 0.9x - 1.0x 1" 107.3 - 121.7 9.3 - 10.3
VS-THV2-110/S-LQL1 - 1.8x - 2.0x 1" 105.6 - 115.8 9.0 - 10.1
VS-THV2-110CO/S-LQL1 O 1.8x - 2.0x 1" 105.6 - 115.8 9.0 - 10.1
VS-TM10-55CO-LQL1 O 10.0x 2/3" 55.28-55.18 23.2-​21.4
